LeopardUV® Amalgam Series Water Treatment System

The LeopardUV® Amalgam Series Water Treatment System processes up to 1600 GPM for clear fresh water and 1600 GPM for RO and DI water. Higher dosages and flow options are available. Flow rates are based on 95% UVT for clear fresh water (CFW) and 99% UVT for RO or DI water and EOL dosage of 30 mJ/cm² or higher at rated flow. Ozone Destruct models process up to 750 GPM based on 99% UVT and EOL dosage of 90 mJ/cm². The LeopardUV® Amalgam Series Water Treatment System has many flexible models to choose from to meet your requirement.  These systems are available in both short and long designs.  The LeopardUV® Amalgam Series Water Treatment System are specifically intended for commercial and industrial applications requiring low flows to high flows and are for disinfection, ozone destruction, or TOC reduction.

Prior experience and a commitment to sound engineering principles is the key to our success. Contact our knowledgeable sales team with your specific requirements and let us size the appropriate system for your application.

Custom Systems and features are available to meet specific specifications and industry requirements. For more information, contact us directly at 770-307-3882 or by clicking here.



Standard Features

  • 316L Electropolished and Passivated Stainless Steel Treatment Chamber
  • 150 PSI Maximum Operating Pressure
  • Flange Inlet/Outlet Connections
  • Monitoring Port
  • Drain Port
  • Sample Port
  • Remote Polycarbonate Electrical Power Enclosure
  • Remote 304 Stainless Steel Electrical Power Enclosure with viewing window
  • Elapsed Running Time Meter
  • LED UV Lamp Status Indicators
  • 254NM Amalgam UV Lamp with 10,000 hour lamp life
  • Horizontal or Vertical Mounting
  • 120V 60Hz

Available Options (All Models):

  • WatchDog Monitoring System with High Heat, UV Intensity, and 4-20mA Linear Output
  • Standard Ultraviolet Monitor with 0-100% UV Intensity Display with 4-20mA Linear Output
  • Lamp Out Alert (LOA)
  • Sanitary Inlet/Outlet Connections
  • Manual Wiper System
  • Remote 304 Stainless Steel Power Enclosure with viewing window
  • Hands Off Auto (HOA) Switch
  • Standard High Heat Shutoff
  • 220V / 240V 50-60HZ
*Certain features and options do not apply to all models.

For more detailed information and a product illustration click LeopardUV® Series Water Treatment System



LeopardUV® Amalgam Series Product Specifications

Treatment:         Disinfection, Ozone Destruction or TOC Reduction

Application:       Commercial and Industrial

Flow Rates*:       up to 1600/1600 GPM

*Flow rates are based on 95% UVT for clear fresh water at 30 mJ/cm² and 99% UVT for RO and DI water at 40 mJ/cm².

Contact UV Superstore for sizing parameters for TOC Reduction and Ozone Destruction models.  Higher dosages and flow options are also available.

For our LeopardUV® High Output Series click here.



For complete product details click on buttons below.

**Dimensional drawings are available upon request. Contact UV Superstore for the specific model you are inquiring about.
